Description:

1.Specification: 4P+Mylar+D+AL

2.Rated Temperature: 60°C or 75°C

3.Unshielded twisted pairs:

4.Conductor: 26AWG or 24AWG Stranding or Solid Bare copper

5.Insulation: HD-PE

6.Drain Wire: 26AWG or 24AWG Stranding or Solid Tinned copper

7.Outer Shielded: AL-Mylar 100%(min) coverage

8.Unrip rope: optional

9.Jacket: PVC or LSNH

10.Impedance:100±15%Ω at 1~100MHz

11.Reference standard: YD/T1019-2001,ISO/IEC11801,ANSI/TIA/EIA-568B,UL 444

12.Flame Retardancy Standard: Passed CM or CMR
