Reted temperature: 60°C, 75°C, 90°c Reference Standard: UL444,UL1581 Bare Solid copper conductor RoHS/REACH Complied PVC Jacket Complies to TIA/EIA-568-C.2& ISO/IEC 11801 Installation temperatu: -30°c±50° | Application: 100 Base-TX 100 Base-T 100VG-AnyLAN 1000 Base-T(Gigabit Ethernet ) ATM Noisy Environments | ||||||
| Content of Data Sheet | |||||||
| Category | U/UTP CAT5-4P-PVC Patch Cord | | |||||
| Test Standard | ISO/IEC11801 TIA-568-C.2 YD/T1019 | ||||||
| Conductor | Material | Solid Bare Copper | |||||
| Nom.O.D(mm) | 0.57 | up | +0.005 | ||||
| oown | -0.005 | ||||||
| Insulation | Material | HDPE 1.02±0.03mm 0.55±0.05mm 6.3±0.4mm Clean,Frap,SatiationPVCAccording to requires 3.0 ± 0.3mm Black ≤±0.5%,1m | |||||
| Diameter | |||||||
| Sheath | Thickness | Sheath Physical Properties | Before Aging Tensile Stength(Mpa)≥10.0 Elongation(%)≥125 | ||||
| External O.D. | Aging Period(°c×hrs) 100°c×24h×7d | ||||||
| Surface | After Aging Tensile Stength(Mpa)≥8.0 Elongation(%)≥100 | ||||||
| Material | Cold Bend(-20± 2°c× 4h 8×Cable O.D. | ||||||
| Color | Electrical Characteristics(20°C) | 1.0-100.0MHz Impedance 100±15 ohm | |||||
| Printing | Letter Height | Delay Shew(ns/100m) ≤45 | |||||
| Color | |||||||
| Print error&Space | NVP 69% | ||||||
| Core Color | 1White-Blue/Blue | 2White- Orange/Orange | Capacitance(nF/100m)max: 5.6 | ||||
| 3 White-Green/Green | 4White-Brown/Brown | ||||||
| Packing | Wooden Tray&Carton | DC Resistance(Ω/100m)max:9.5 | |||||
| Carton Dimension | 40.5cm ×40.5cm ×21cm | ||||||
| Patch Cord Packing Length | 305 ±1.5m | DC Conductor Resistance Unbalance(%)max 5.0 | |||||
| Rip-cord | YES | Drin Wire | NO | ||||
